• 700 MHz to 20 GHz
• Compensation for Temperature Drift
• Input Regulators for Improved Stability
  - Versus Power Supply Variations
• 12 Bit Tuning Resolution
• -40º C to +85º C Temperature Range

DESCRIPTION
MICRO LAMBDA YIG Oscillators, model type MLOB, MLOS, MLXB, MLXS and MLXS-T Series units are available with integrated digital driver circuits.

MICRO LAMBDA drivers eliminate the need for customers to design or develop their own driver circuits and sophisticated test and alignment procedures. Integrating a driver at MICRO LAMBDA’s factory ensures that peak performance will be achieved at the time of manufacture. Alignment and compensation with the particular YIG oscillator can be maximized down to the component level.

All drivers in this series provide input voltage regulators, and compensation circuits to improve frequency drift.

Micro Lambda Wireless, Inc. - 46515 Landing Parkway, Fremont CA 94538  *  Tel: (510) 770-9221   *  Fax (510) 770-9213

PDF Format Data Sheet

Component Data Sheets:
MLOB Series (Octave Band)     MLOB Series (Multi-Octave Band)
MLOS Series (Octave Band)     MLOS Series (Multi-Octave Band)
MLOS-P Series     MLXS-T Series     MLXS-Series     MLXB-Series
